Name: MapQuadIndex100k

Display Field: quad_name

Type: Feature Layer

Geometry Type: esriGeometryPolygon

Description: This web service contains an index map of published geologic maps at a scale of 1:100,000 in the state of Wyoming.

Service Item Id: 01ec3d7dd38c4ad29c2e244cd949d992

Copyright Text: Wyoming State Geological Survey (WSGS)

Default Visibility: true

MaxRecordCount: 2000

MaxSelectionCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 0.0

Max Scale: 0.0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: true

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: -1.23565512548E7
YMin: 5012334.686499998
XMax: -1.15772820111E7
YMax: 5621520.844300002
Spatial Reference: 102100  (3857)  LatestVCSWkid(0)

Drawing Info:

Renderer:
Unique Value Renderer:
Field 1: quad_status
Field 2: N/A
Field 3: N/A
Field Delimiter: ,
Default Symbol:
N/A
Default Label: N/A
UniqueValueInfos:
• Value: Bedrock Unmapped | Surficial Unmapped
  Label: Bedrock Unmapped | Surficial Unmapped
  Description: N/A
  Symbol:
  Style: esriSFSSolid
  Color: [0, 0, 0, 0]
  Outline:
  Style: esriSLSSolid
  Color: [110, 110, 110, 255]
  Width: 0
• Value: Bedrock Unmapped | Surficial Mapped
  Label: Bedrock Unmapped | Surficial Mapped
  Description: N/A
  Symbol:
  Style: esriSFSSolid
  Color: [190, 232, 255, 255]
  Outline:
  Style: esriSLSSolid
  Color: [110, 110, 110, 255]
  Width: 0
• Value: Bedrock Mapped | Surficial Mapped
  Label: Bedrock Mapped | Surficial Mapped
  Description: N/A
  Symbol:
  Style: esriSFSSolid
  Color: [255, 211, 127, 255]
  Outline:
  Style: esriSLSSolid
  Color: [110, 110, 110, 255]
  Width: 0
• Value: Bedrock Unmapped | Surficial In Progress
  Label: Bedrock Unmapped | Surficial In Progress
  Description: N/A
  Symbol:
  Style: esriSFSBackwardDiagonal
  Color: [115, 223, 255, 255]
  Outline:
  Style: esriSLSSolid
  Color: [110, 110, 110, 255]
  Width: 0
Transparency: 0
Labeling Info:
Label Placement: esriServerPolygonPlacementAlwaysHorizontal
Label Expression: N/A
Use Coded Values: true
Symbol:
Color: [0, 0, 0, 255]
Background Color: N/A
Outline Color: N/A
Vertical Alignment: bottom
Horizontal Alignment: center
Right to Left: false
Angle: 0
XOffset: 0
YOffset: 0
Size: 8
Font Family: Arial
Font Style: normal
Font Weight: normal
Font Decoration: none

Min. Scale: 5000000.0
Max. Scale: 0.0

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false
Supports Percentile Statistics: true
Supports Having Clause: true
Supports Count Distinct: true
Supports Time Relation: true
Supports Sql Format: false
Supports Query Analytic: false
Supports Query With Current User: true

HasZ: false

HasM: false

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field: null

Fields:

• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID )
• Shape ( type: esriFieldTypeGeometry, alias: Shape )
• quad_name ( type: esriFieldTypeString, alias: Quad_Name, length: 32 )
• usgs_id ( type: esriFieldTypeString, alias: USGS_ID, length: 8 )
• utm_zone ( type: esriFieldTypeString, alias: UTM_Zone, length: 2 )
• quad_status ( type: esriFieldTypeString, alias: Quad_Status, length: 50 )
• quad_symbol ( type: esriFieldTypeString, alias: Quad_Symbol, length: 50 )
• bedrock_status ( type: esriFieldTypeString, alias: Bedrock_Status, length: 15 )
• bedrock_publisher ( type: esriFieldTypeString, alias: Bedrock_Publisher, length: 100 )
• bedrock_pub_series ( type: esriFieldTypeString, alias: Bedrock_Pub_Series, length: 100 )
• bedrock_pub_number ( type: esriFieldTypeString, alias: Bedrock_Pub_Number, length: 50 )
• bedrock_pub_year ( type: esriFieldTypeString, alias: Bedrock_Pub_Year, length: 4 )
• bedrock_pub_title ( type: esriFieldTypeString, alias: Bedrock_Pub_Title, length: 200 )
• bedrock_pub_citation ( type: esriFieldTypeString, alias: Bedrock_Pub_Citation, length: 350 )
• bedrock_pub_link ( type: esriFieldTypeString, alias: Bedrock_Pub_Link, length: 250 )
• bedrock_funding ( type: esriFieldTypeString, alias: Bedrock_Funding, length: 10 )
• bedrock_notes ( type: esriFieldTypeString, alias: Bedrock_Notes, length: 500 )
• surficial_status ( type: esriFieldTypeString, alias: Surficial_Status, length: 15 )
• surficial_publisher ( type: esriFieldTypeString, alias: Surficial_Publisher, length: 50 )
• surficial_pub_series ( type: esriFieldTypeString, alias: Surficial_Pub_Series, length: 50 )
• surficial_pub_number ( type: esriFieldTypeString, alias: Surficial_Pub_Number, length: 15 )
• surficial_pub_year ( type: esriFieldTypeString, alias: Surficial_Pub_Year, length: 4 )
• surficial_pub_title ( type: esriFieldTypeString, alias: Surficial_Pub_Title, length: 200 )
• surficial_pub_citation ( type: esriFieldTypeString, alias: Surficial_Pub_Citation, length: 350 )
• surficial_pub_link ( type: esriFieldTypeString, alias: Surficial_Pub_Link, length: 250 )
• surficial_funding ( type: esriFieldTypeString, alias: Surficial_Funding, length: 10 )
• surficial_notes ( type: esriFieldTypeString, alias: Surficial_Notes, length: 500 )
• bedrock_gems_status ( type: esriFieldTypeString, alias: Bedrock_GeMS_Status, length: 16 )
• bedrock_gems_publisher ( type: esriFieldTypeString, alias: Bedrock_GeMS_Publisher, length: 100 )
• bedrock_gems_series ( type: esriFieldTypeString, alias: Bedrock_GeMS_PubSeries, length: 100 )
• bedrock_gems_number ( type: esriFieldTypeString, alias: Bedrock_GeMS_PubNumber, length: 50 )
• bedrock_gems_year ( type: esriFieldTypeString, alias: Bedrock_GeMS_PubYear, length: 4 )
• bedrock_gems_title ( type: esriFieldTypeString, alias: Bedrock_GeMS_PubTitle, length: 200 )
• bedrock_gems_citation ( type: esriFieldTypeString, alias: Bedrock_GeMS_PubCitation, length: 350 )
• bedrock_gems_link ( type: esriFieldTypeString, alias: Bedrock_GeMS_PubLink, length: 250 )
• bedrock_gems_funding ( type: esriFieldTypeString, alias: Bedrock_GeMS_Funding, length: 16 )
• bedrock_gems_notes ( type: esriFieldTypeString, alias: Bedrock_GeMS_Notes, length: 500 )
• globalid ( type: esriFieldTypeGlobalID, alias: globalid, length: 38 )
• created_user ( type: esriFieldTypeString, alias: created_user, length: 255 )
• created_date ( type: esriFieldTypeDate, alias: created_date, length: 8, precision: 1 )
• last_edited_user ( type: esriFieldTypeString, alias: last_edited_user, length: 255 )
• last_edited_date ( type: esriFieldTypeDate, alias: last_edited_date, length: 8, precision: 1 )
• Shape_Length ( type: esriFieldTypeDouble, alias: Shape_Length )
• Shape_Area ( type: esriFieldTypeDouble, alias: Shape_Area )

Supported Operations:   Query   Query Attachments   Query Analytic   Generate Renderer   Return Updates

  Iteminfo   Thumbnail   Metadata
